AArch64 MP+dmb.sy+addr-rfi-ctrl-[fr-rf]-addr
"DMB.SYdWW Rfe DpAddrdW Rfi DpCtrldR FrLeave RfBack DpAddrdR Fre"
Cycle=Rfi DpCtrldR FrLeave RfBack DpAddrdR Fre DMB.SYdWW Rfe DpAddrdW
Relax=
Safe=Rfi Rfe Fre DMB.SYdWW DpAddrdW DpAddrdR DpCtrldR [FrLeave,RfBack]
Prefetch=0:x=F,0:y=W,1:y=F,1:x=T
Com=Rf Fr Rf
Orig=DMB.SYdWW Rfe DpAddrdW Rfi DpCtrldR FrLeave RfBack DpAddrdR Fre
{
0:X1=x; 0:X3=y;
1:X1=y; 1:X4=z; 1:X7=a; 1:X11=x;
2:X1=a;
}
P0 | P1 | P2 ;
MOV W0,#1 | LDR W0,[X1] | MOV W0,#1 ;
STR W0,[X1] | EOR W2,W0,W0 | STR W0,[X1] ;
DMB SY | MOV W3,#1 | ;
MOV W2,#1 | STR W3,[X4,W2,SXTW] | ;
STR W2,[X3] | LDR W5,[X4] | ;
| CBNZ W5,LC00 | ;
| LC00: | ;
| LDR W6,[X7] | ;
| LDR W8,[X7] | ;
| EOR W9,W8,W8 | ;
| LDR W10,[X11,W9,SXTW] | ;
Observed
z=1; y=1; x=1; a=1; 1:X8=0; 1:X6=1; 1:X5=1; 1:X10=1; 1:X0=1;
and z=1; y=1; x=1; a=1; 1:X8=0; 1:X6=1; 1:X5=1; 1:X10=0; 1:X0=1;
and z=1; y=1; x=1; a=1; 1:X8=0; 1:X6=1; 1:X5=1; 1:X10=1; 1:X0=0;
and z=1; y=1; x=1; a=1; 1:X8=0; 1:X6=1; 1:X5=1; 1:X10=0; 1:X0=0;
